High Speed Disperser Structure

1. Dispersing disc: Located at the bottom of high speed disperser, responsible for shearing and dispersing materials, it is the main component.
2. Shaft: Connects the motor the disc, and carries torque transmission.
3. Motor: Provides power, often equipped with a frequency converter to achieve speed adjustment (generally 0-3000rpm).
4. Hydraulic lifting system: Used to lift/lower the mixing head for easy loading and unloading and cleaning.
5. Material tank: Container for materials, optionally with a jacket for heating or cooling.
6. Control system: Optional PLC automatic control or manual button operation.

High Speed Disperser Working Principle

When the dispersing disc rotates at high speed, the surrounding liquid forms a turbulent circulation, which quickly draws the solid powder into the shear zone. Through strong  mechanical shear force, turbulent impact and friction, the powder is refined, deagglomerated and evenly dispersed in the liquid phase.

High Speed Disperser Advantages

• High dispersion efficiency, suitable for medium and low viscosity materials.
• Compact structure, simple operation and easy maintenance.
• Variable frequency speed regulation, suitable for different materials.
• Lifting structure is convenient for cleaning and changing materials.
• Optional explosion-proof design to meet safety production requirements.

If you are considering configuring a high speed disperser, as a professional equipment manufacturer with more than 20 years of experience, we can provide you with:

• Customized specifications
• Stainless steel / explosion-proof / with heating structure optional
• Complete dispersion system (including lifting system, mixing tank, control cabinet) can be equipped with a press
• Domestic and foreign installation and commissioning support
