Product: Conical double spiral mixer

let me see pictures:

Equipment Introduction：

1) The agitating part of the conical double-spiral mixer is two asymmetric cantilever spirals; one for each length, they are rotating (rotating) around their own axis .At the same time, it also surrounds the central axis of the conical container; the planetary movement (revolution) is made near the wall of the cone by the rotation of the rotary arm;The rotation and rotation of the material repeatedly lift the material, which results in the formation of shear, convection, diffusion and other composite movements within the cone, so that the materials are evenly mixed..

2) The product can be designed with outer jacket (heating, cooling), sprayer liquid adding device. Can be made according to user requirements Pressure, vacuum and other special forms.

3) Feeding method: manual feeding, vacuum suction, screw conveying.

4) Discharging method: The standard type equipment generally adopts a plum-shaped “displacement valve”. This valve fits tightly with the bottom of the long spiral to effectively reduce mixing.Dead angle, the driving mode is manual and pneumatic; according to user needs, butterfly valve, ball valve, star unloader, side discharge, etc. can also be installed.

5) Equipment material: SS316L, SS304 stainless steel, Q235 carbon steel.

Application range：

The conical mixer is widely used in chemical, pharmaceutical, pesticide, dye, building materials and other powder mixing and reaction.
